D3.3*L6.5 STS Project Pneumatic Rubber Fenders BV CCS DNV Certification
Description
| Product Name | Pneumatic Fender | Material | Natural Rubber |
| Certification | CCS;BV;DNV:ABS | Application | STS;STD |
|
Brand Name |
LUHANG | Interal Presssure | 50kPa;80kPa |
| Size | Customized | Color |
Black;Gray;Customized |
| Highlight:ISO17357 Certified Pneumatic Marine Fender, Resistant Yokohama Type Fender with Tyre-chain Net, New Type Pneumatic Rubber Fender Natural Rubber |
|||
Introduction
Luhang inflatable rubber fenders meet all ISO17357:2002 standard requirements. They're certified by CCS, DNV, ABS, LR, and BV.
Our ISO17357:2014 floating fenders are used worldwide to prevent collisions between ships. Made from reinforced rubber and filled with compressed air, they float and cushion impacts during ship-to-ship transfers and docking.
The inflatable pneumatic rubber fender is basically made of three layers: an outer rubber layer, a middle layer of synthetic tire cord, and an inner rubber layer. See the picture for a clearer idea. These layers are bonded together through vulcanization. Compressed air is then pumped inside, allowing the fender to float on water.
Size and performance ratings for inflatable boat fenders--50kPa
| DiameterxLength (mm) |
Initial internal pressure (kPa) |
Energy (kj) |
Reaction (kN) |
Hull pressue (kPa) |
|---|---|---|---|---|
| 500x1000 | 50 | 6 | 64 | 132 |
| 600x1000 | 50 | 8 | 74 | 126 |
| 700x1500 | 50 | 17 | 137 | 135 |
| 1000x1500 | 50 | 32 | 182 | 122 |
| 1000x2000 | 50 | 45 | 257 | 132 |
| 1200x2000 | 50 | 63 | 297 | 126 |
| 1350x2500 | 50 | 102 | 427 | 130 |
| 1500x3000 | 50 | 153 | 579 | 132 |
| 1700x3000 | 50 | 191 | 639 | 128 |
| 2000x3500 | 50 | 308 | 875 | 128 |
| 2500x4000 | 50 | 663 | 1381 | 137 |
| 2500x5500 | 50 | 943 | 2019 | 148 |
| 3300x4500 | 50 | 1175 | 1884 | 130 |
| 3300x6500 | 50 | 1814 | 3015 | 146 |
| 4500x9000 | 50 | 4752 | 5747 | 146 |
Project application cases
Exhibitons
Contact Us
Please do not hesitate to drop us a message here or send us an email for inquiry about our pneumatic fenders if you have any demand.
