Product introduction
Floating dock fender is the advanced anti-collision device for marine application in the world. Floating dock fenders also known as pneumatic rubber fender or Yokohama type rubber fender. Our pneumatic fenders are commonly mounted on terminals or ships to absorb or minimize the impact energy during ship-to-ship or ship-to-dock interactions. These fenders serve to shield both the ship and the dock from collision damage. Operated by compressed air, they have the ability to float on water and are extensively utilized as protective equipment. Our pneumatic fenders excel in energy absorption and have minimal reaction forces, making them well-suited for ship-ship tasks and rapid response requirements. Their lightweight yet durable construction reflects our innovative strategy, merging cutting-edge technology with functional design.
Maintenance and safety knowledge
Ship to ship berthing
Accompanied by a large ship, the risk of two ship berthing at sea is also increased, especially when the weather changes, accompanied by wind and waves.Adopt pneumatic fender as side of the buffer, not only make heavy berthing becomes easy, and improve the efficiency of the transportation operations. Floating dock fender is mainly used for: Ice in the Antarctic ocean fishing ships, large oil tanker berthing.
Precautions for installation of inflatable fenders:
1. Inflatable dock fenders should be installed on a solid deck or on the outside of the hull, and ensure that they are not subject to impact or friction.
2. Before installing the inflatable fender, check whether its appearance is intact and make sure there are no cracks, bubbles, deformation, etc.
3. When installing inflatable fenders, the instructions or drawings provided by the manufacturer should be followed. Special tools and materials should be used to ensure correct installation.
4. When installing inflatable fenders, pay attention to safety to avoid accidents.
Size and Specification
The floating dock fender provide protection in both dockside and ship to ship berthing scenarios. We offer a wide range of sizes and they can also be fitted with a tire/chain net for additional protection.
1. Normal size and customized size available. please refer to below sheet.
|
LUHANG Pneumatic Rubber Fenders General Products List |
||||
|
Specifications (mm) |
At 60% compression; |
Fender Boday Weight |
||
|
Initial Pressure is 0.05MPa |
±10% |
|||
|
Diameter |
Length |
Energy Absorption |
Reaction Force |
KG |
|
(KJ) |
(KN) |
|||
|
200 |
500 |
2 |
25 |
6 |
|
300 |
500 |
3 |
32 |
12 |
|
500 |
1000 |
6 |
64 |
25 |
|
600 |
1200 |
10 |
86 |
35 |
|
700 |
1500 |
17 |
137 |
50 |
|
1000 |
1500 |
32 |
181 |
80 |
|
1000 |
2000 |
45 |
257 |
100 |
|
1200 |
2000 |
63 |
297 |
120 |
|
1350 |
2500 |
100 |
426 |
170 |
|
1500 |
3000 |
153 |
579 |
320 |
|
1700 |
3000 |
190 |
637 |
400 |
|
2000 |
3500 |
308 |
875 |
590 |
|
2500 |
4000 |
663 |
1380 |
1000 |
|
2500 |
5500 |
932 |
2010 |
1400 |
|
3000 |
5000 |
1050 |
2030 |
1800 |
|
3000 |
6000 |
1315 |
2488 |
2200 |
|
3300 |
6500 |
1814 |
3015 |
2700 |
|
3500 |
6000 |
2018 |
3286 |
2800 |
|
3500 |
6500 |
2325 |
3656 |
3200 |
|
3500 |
7000 |
2650 |
4018 |
3600 |
|
3600 |
7200 |
3180 |
4821 |
4320 |
|
Remark |
1, We can also provide Pneumatic Rubber Fenders with an initial pressure of 0.08MPa. |
|||
|
2, Customization options are available for sizes beyond those listed. |
||||
|
3, Every fender complies with the most recent guidelines set forth by ISO 17357. |
||||
|
4, A wide range of marine fenders filled with various types of foam can be sourced. |
||||
|
5, The item can be shipped in different dimensions along with a chain - suitable for vehicle or aircraft tires. |
||||
2. And the customized size are available. You just need to tell us the diameter, length and initial pressure you need.
The following factors should be considered in the selection of pneumatic fenders:
(1) Maximum energy absorption E;
(2) Reaction force;
(3) The distance regulations following the docking of two ships, or the distance between a ship and the dock upon berthing, encompass both the furthest and closest allowable distances.
(4) The size of the ship;
(5) Factors such as wind waves and temperature changes in the actual use environment.
